Model Name

MS-S500

LCD Panel

Technology: 21.3� monochrome TFT IPS technology

Display Area: 337.9 mm x 422.4 mm

Pixel Pitch: 0.165 mm x 0.165 mm

Maximum Luminance: 3000 cd/m² (typ.)
500 cd/m² / 1000 cd/m² (calibrated)

Contrast Ratio: 2000:1 (typ.)

Viewing Angle: 178� vertical and horizontal

Visual Performance

Native Resolution: 2048 x 2560 (Independent Sub-pixel Drive technology ON : 2048 x 7680)

Display Colors: 256 shades of grayscale are simultaneously displayed from a palette of 16,369 grayscale steps
*1024 or 10-bit shades of grayscale with DisplayPort and 10-bit viewer
*1276 shades of grayscale by using Independent Sub-pixel Drive technology

Interface

Input Signal: DVI-D (DVI 1.0 compliant)
DisplayPort (DisplayPort 1.2a compliant)

Output Signal: DisplayPort (DisplayPort 1.2a compliant)

Plug and Play: DDC2B compliant

Input Power Supply

Input Power Supply: 100V - 240 V 50/60 Hz

Power Consumption: 35W (typ.)

Features

Calibration Control: Luminance, Gamma, Capable of storing 3 sets of LUT (Optional Calibration Kit is required)

OSD Information Display: Model name, Serial No., Total operating time, Calibration settings (Operating time since last calibration, Luminance, Gamma), Current luminance, Ambient light, DICOM conformance

USB Hub: USB Rev.2 compliant, Self-powered
USB upstream connector (x1), USB downstream connector (x2)

Other Features: Uniformity Equalizer, Hardware pivot, LED indicator, Advanced power management, Human Presence Sensor, Independent Sub-pixel Drive technology, Auto Text Mode, Reading light, Luminance stabilization, Multiple LUT, Self DICOM check, Self-calibration

Approvals*Please contact JVC for latest information.

ANSI/AAMI ES60601-1 (2005) + A1 (2012), CAN/CSA-C22.2 No. 60601-1 (2014), CE (EN60601-1, EN60601-1-2), RCM, FCC Part15 subpart B Class B, ICES-003-B, VCCI-B, FDA 510(k), J-Moss, RoHS, EAC, KC

FDA

510(k) Cleared to use for diagnostic purposes with digital medical images for Digital mammography PACS, Modalities including FFDM, and Breast tomosynthesis

Physical Characteristics
